Specifications
A-2 www.zoll.com 9650-001355-01 Rev. M
Defibrillator
Charge Time:
• Less than 7 seconds with a new, fully charged battery (first 15 charges to 200 joules).
• For the sixteenth discharge at maximum energy, the charge time is less than 10 seconds.
Depleted batteries result in a longer defibrillator charge time.
• Less than 15 seconds when operating without a battery, using AC power alone at 90% of the
rated mains voltage.
• Less than 25 seconds from the initial power on, with a new, fully charged battery pack
(depleted by up to fifteen 200 joule discharges) or when operating without a battery, using
AC power alone at 90% of the rated mains voltage.
Rhythm Analysis and Charge Time in AED Mode
• Less than 30 seconds with a new, fully charged battery (first 15 charges to 200 joules).
• For the sixteenth discharge at maximum energy, the analysis and charge time is less than 30
seconds. Depleted batteries result in a longer defibrillator charge time.
• Less than 30 seconds when operating without a battery, using AC power alone at 90% of the
rated mains voltage.
• Less than 40 seconds from the initial power on, with a new, fully charged battery pack
(depleted by up to fifteen 200 joule discharges) or when operating without a battery, using
AC power alone at 90% of the rated mains voltage.
Patient Impedance Range: 10- 300 ohms
Synchronized Mode: Synchronizes defibrillator discharge to the patient’s R wave. SYNC is
indicated on the display with R wave markers above the ECG waveform on the screen and
stripchart. When ECG is monitored by the device, meets the DF-80:2003 requirement of 60ms
maximum time delay between the peak of the R wave and the delivery of energy.
Table A-1 shows the characteristics of the X Series Rectilinear Biphasic™ waveform when
discharged into 25 ohm, 50 ohm, 100 ohm, 125 ohm, 150 ohm and 175 ohm loads at the
maximum energy setting of 200 joules.
Table A-1. X Series Rectilinear Biphasic Waveform Characteristics
200 J discharged into
25 50 100 125 150 175
First phase
Maximum initial current 31.4 A 30.4 A 19.7 A 19.4 A 16.7 A 15.6 A
Average current 27.1 A 24.9 A 17.5 A 16.2 A 14.4 A 13.2 A
Duration 6 ms 6 ms 6 ms 6 ms 6 ms 6 ms
Interphase duration
(between first and
second phases)
200 s 200 s 200 s 200 s 200 s200 s
Second phase
Initial current 29.2 A 18.8 A 15.1 A 13.2 A 12.1 A 11 A
Average current 14.7 A 13 A 12.5 A 11.3 A 10.7 A 9.9 A
Duration 4 ms 4 ms 4 ms 4 ms 4 ms 4 ms
