Defibrillator
9650-001355-01 Rev. M X Series Operator’s Guide A-3
* For all energy levels, accuracy is equal to either ±15% or 3 joules, whichever is greater.
The X Series Rectilinear Biphasic waveform employs the same first and second phase timing,
similar first and second phase currents/voltages, and essentially the same mechanisms for
controlling defibrillation waveshape as the ZOLL R Series
®
defibrillator. The R Series and X
Series defibrillation waveforms are considered substantially equivalent.
Figures A-1 through A-20 show the Rectilinear Biphasic waveforms that are produced when
the X Series defibrillator is discharged into loads of 25, 50, 75, 100, 125, 150, and 175 ohms at
each energy setting.
Table A-2. Delivered Energy at Every Defibrillator Setting into a Range of Loads
Selected
Energy
Load
25 50 75 100 125 150 175 Accuracy*
1 J 1 J1 J1 J 1 J 1 J1 J1 J±15%
2 J 1 J 2 J2 J2 J2 J2 J2 J±15%
3 J 2 J3 J3 J 3 J3 J3 J3 J±15%
4 J 3J 4 J 4 J 5 J 5 J 5 J 4 J ±15%
5 J 3 J5 J6 J6 J6 J6 J6 J±15%
6 J 4 J6 J 7 J7 J7 J7 J7 J±15%
7 J 5 J7 J8 J8 J8 J8 J8 J±15%
8 J 5 J8 J9 J9 J10 J9 J9 J±15%
9 J 6 J 9 J 10 J 11 J 11 J 11 J 10 J ±15%
10 J 7 J 10 J 12 J 12 J 12 J 12 J 12 J ±15%
15 J 10 J 16 J 17 J 18 J 18 J 18 J 17 J ±15%
20 J 14 J 21 J 23 J 24 J 24 J 24 J 23 J ±15%
30 J 21 J 32 J 35 J 36 J 37 J 36 J 35 J ±15%
50 J 35 J 54 J 59 J 61 J 62 J 61 J 59 J ±15%
70 J 49 J 76 J 83 J 85 J 87 J 86 J 83 J ±15%
85 J 60 J 92 J 101 J 104 J 106 J 104 J 101 J ±15%
100 J 71 J 109 J 119 J 122 J 125 J 123 J 119 J ±15%
120 J 85 J 131 J 143 J 147 J 150 J 147 J 143 J ±15%
150 J 107 J 164 J 180 J 183 J 188 J 184 J 179 J ±15%
200 J 142 J 230 J 249 J 253 J 269 J 261 J 260 J ±15%
