ZOLL X Series User Manual

Chapter 22 Communications
22-12 www.zoll.com 9650-001355-01 Rev. M
Sending a 12-Lead Report
When a 12-lead report has been acquired or a previously acquired 12-lead has been selected for
review, the X Series unit prepares the report for transmission. When this is complete, the
Transmit quick access key( ) displays.
To send a 12-lead report to a preconfigured distribution list:
1. Press the 12-lead quick access key( ).
2. If desired, press the snapshot button( ) to take a 12-lead snapshot (see Chapter 14: 12-Lead
ECG Interpretive Analysis for more information about acquiring 12-lead data).
3. Press the 12-lead review next quick access key ( ). A list of snapshots appears; select the
desired snapshot.
4. Press . A list of preconfigured distribution lists appears.
Use the navigation keys to highlight and select the desired distribution list. A green check
box indicates the selected list.When a destination has been selected, the Transmit button is
enabled.
5. Press Transmit to initiate the 12-lead transmission.
While the transmission is in process, the green LED on top of the unit is illuminated and a
message appears on the screen.

ZOLL X Series Specifications

General

Type	Defibrillator/Monitor
Display	Color LCD
ECG Monitoring	Yes
Pacing	Yes
SpO2 Monitoring	Yes
NIBP Monitoring	Yes
Defibrillator Type	Biphasic
EtCO2 Monitoring	Optional
Data Storage	Yes
Battery	Rechargeable Lithium-ion
CPR Feedback	Real CPR Help
Energy Selection	1-360 J
Pacing Rate	30 – 180 ppm
Pacing Output	0 – 140 mA
Display Size	6.5 inches
Invasive Pressure Monitoring	Optional
Temperature Monitoring	Optional
Wireless Connectivity	Wi-Fi, Bluetooth
