ZOLL X Series User Manual

Chapter 11 Monitoring Invasive Pressures (IBP)
11-4 www.zoll.com 9650-001355-01 Rev. M
Zeroing the Transducer
To ensure that the X Series unit measures pressure accurately, you must zero the transducer
before each use. If you change or disconnect a transducer, you must zero the new transducer
before use. If you move a transducer to a different monitor, you must zero the transducer again,
even if you have already done so on another unit. In addition to the procedure below, follow the
transducer manufacturer’s Directions for Use and your organization’s established clinical
protocol.
Follow these steps when zeroing a transducer:
1. Place the transducer at the same height as the patient’s left atrium.
2. Close the transducer stopcock to the patient.
3. Open the transducer’s venting stopcock to atmospheric air.
4. Allow the transducer a few seconds to settle.
5. Use the navigation keys to highlight and select the tranducer’s IBP channel and display the
IBP channel’s parameter control panel:
Figure 11-2 IBP Channel Parameter Control Panel
6. Select Zero Probe. The unit displays the message ZEROING in the IBP Channel’s numeric
display.
7. The message ZEROED appears in the IBP channel’s numeric display.
8. Close the transducer’s stopcock.
9. If the unit was unable to zero the transducer, the message ZERO REJECTED appears in the
IBP channel’s numeric display. The unit will not display pressure values for the IBP channel
until it has successfully zeroed the transducer and established an acceptable zero reference.
Check that the unit is open to atmospheric air and that it is properly connected to the unit, then
try zeroing the transducer again. The X Series unit will not zero the transducer if it detects
pulsation in the pressure channel, if there is too much noise in the signal, or if transducer’s
offset is too great.
If you cannot zero the transducer after several attempts, replace the transducer or the transducer
cable.
P1
Lower Upper
P1 Systolic Alarm 90
150
Source Label P1
Display Format S/D (M)
P1 Diastolic Alarm 60
90
P1 Mean Alarm 70
120
Zero Probe

ZOLL X Series Specifications

General

Type	Defibrillator/Monitor
Display	Color LCD
ECG Monitoring	Yes
Pacing	Yes
SpO2 Monitoring	Yes
NIBP Monitoring	Yes
Defibrillator Type	Biphasic
EtCO2 Monitoring	Optional
Data Storage	Yes
Battery	Rechargeable Lithium-ion
CPR Feedback	Real CPR Help
Energy Selection	1-360 J
Pacing Rate	30 – 180 ppm
Pacing Output	0 – 140 mA
Display Size	6.5 inches
Invasive Pressure Monitoring	Optional
Temperature Monitoring	Optional
Wireless Connectivity	Wi-Fi, Bluetooth
