ZOLL X Series User Manual

Chapter 10 Pulse CO-Oximetry (SpO2)
10-16 www.zoll.com 9650-001355-01 Rev. M
SpO2 System Messages
The X Series unit may display the following system messages when monitoring SpO
2
:
System Message Cause
INITIALIZING The SpO
2
pulse oximeter is initializing.
SEARCHING The unit is searching for a pulse.
CHECK SENSOR The SpO
2
sensor has become disconnected from the
unit, or the sensor is no longer on the patient. Check
sensor and then reconnect it to the unit or reapply it to the
patient.
SENSOR FAILURE The SpO
2
sensor is defective. Replace the sensor.
CABLE FAILURE The SpO2 cable is defective. Replace the cable.
LIFE EXPIRING Adhesive/Sensor/Cable Failure. The adhesive/sensor/
cable is nearing expiration. Replace the adhesive/
sensor/cable.
LOW PERFUSION Signal too small, move to better perfused site.
SPO2 DISABLED A system error has occurred. The X Series unit cannot
take SpO
2
measurements and should be serviced.
TIME LEFT: XX:X HRS For sensors that support expiration, indicates the
approximate time left before sensor expiration.

ZOLL X Series Specifications

General

Type	Defibrillator/Monitor
Display	Color LCD
ECG Monitoring	Yes
Pacing	Yes
SpO2 Monitoring	Yes
NIBP Monitoring	Yes
Defibrillator Type	Biphasic
EtCO2 Monitoring	Optional
Data Storage	Yes
Battery	Rechargeable Lithium-ion
CPR Feedback	Real CPR Help
Energy Selection	1-360 J
Pacing Rate	30 – 180 ppm
Pacing Output	0 – 140 mA
Display Size	6.5 inches
Invasive Pressure Monitoring	Optional
Temperature Monitoring	Optional
Wireless Connectivity	Wi-Fi, Bluetooth
