ZOLL X Series User Manual

Chapter 22 Communications
22-2 www.zoll.com 9650-001355-01 Rev. M
The Wireless Icon
The wireless icon is located to the right of the patient mode in the display screen. It has five
possible states shown the table below. If wireless connectivity is disabled, no icon is displayed.
State Description
Connected Wireless connectivity is active using WiFi, Bluetooth, or USB cellular
modem. For Wifi, this is the normal operating state. For Bluetooth or
cellular modem, this icon appears only when a transmission is
requested.
Not connected Wireless connectivity is inactive. If a WiFi access point is selected, this
icon indicates the selected network cannot connect due to incorrect
configuration or weak/no signal strength. If the unit is configured to use
Bluetooth or cellular modem, the unit will show this icon until a
transmission is requested.
Failed Wireless communication hardware has failed.
Ethernet Connected Replaces the wireless icon when Ethernet is enabled. An adapter is
connected, and the connection is operating.
Ethernet Not
Connected
Replaces the wireless icon when Ethernet is enabled.An Ethernet
adapter is connected, but the connection is not operating.
No icon All wireless connectivity is disabled.

ZOLL X Series Specifications

General

Type	Defibrillator/Monitor
Display	Color LCD
ECG Monitoring	Yes
Pacing	Yes
SpO2 Monitoring	Yes
NIBP Monitoring	Yes
Defibrillator Type	Biphasic
EtCO2 Monitoring	Optional
Data Storage	Yes
Battery	Rechargeable Lithium-ion
CPR Feedback	Real CPR Help
Energy Selection	1-360 J
Pacing Rate	30 – 180 ppm
Pacing Output	0 – 140 mA
Display Size	6.5 inches
Invasive Pressure Monitoring	Optional
Temperature Monitoring	Optional
Wireless Connectivity	Wi-Fi, Bluetooth
