Changing the Trends Status Window Display
9650-001355-01 Rev. M X Series Operator’s Guide 4-5
Continuous Waveform Recording
Continuous waveform recording allows you to record continuous waveforms to a full
disclosure case log for the patient being monitored. This feature needs to be enabled by a
supervisor. The supervisor can access this feature by pressing the Setup quick access key ( ),
and then selecting Supervisor>Log>Waveform Recording. In this menu, the following settings
can be customized:
• Record Displayed Waveforms – Record only the top waveform that is displayed or record
all waveforms that are displayed.
• Record Additional Waveforms – Always record the CO
2
waveform or always record the
IBP and the CO
2
waveforms.
There is an additional waveform that can be enabled in the Waveform Recording menu. This
option, Record Pads Imp. Waveform, measures the patient’s impedance between
defibrillation electrodes.
Note: When Continuous waveform recording is disabled, no waveforms (except snapshots)
are recorded.
The full disclosure case can, at a minimum, concurrently store the following information:
• 32 monitor snapshots
• 500 non-ECG events
• 24 hours of continuous ECG (4 waveforms), Capnography, IBP (3 channels), and Pads
Impedance
The actual information that is stored depends on usage. Also, the specific combination of stored
continuous waveform data depends on how the waveform recording settings are configured in
the Supervisor menu.
