ZOLL X Series User Manual

9650-001355-01 Rev. M X Series Operator’s Guide 19-1
Chapter 19
Real CPR Help
WARNING! Do not use Adult CPR electrodes with patients under 8 years of age.
When used with CPR-D-padz or OneStep CPR electrodes, the X Series unit can provide
rescuers with feedback about the quality of CPR they are delivering to their patients. The way
in which feedback is provided varies with respect to the operational mode and user
configuration, but is derived from compression rate and depth measurements.
When applied according to package instructions, ZOLL CPR-D-padz and OneStep CPR
electrodes provide a chest compression sensor that is located between the rescuer's hands and
the patient's lower sternum. This sensor monitors the rate and depth of chest compressions and
sends this information to the X Series unit for processing and display.
Real CPR Help is defibrillation-proof Type BF equipment.

ZOLL X Series Specifications

General

Type	Defibrillator/Monitor
Display	Color LCD
ECG Monitoring	Yes
Pacing	Yes
SpO2 Monitoring	Yes
NIBP Monitoring	Yes
Defibrillator Type	Biphasic
EtCO2 Monitoring	Optional
Data Storage	Yes
Battery	Rechargeable Lithium-ion
CPR Feedback	Real CPR Help
Energy Selection	1-360 J
Pacing Rate	30 – 180 ppm
Pacing Output	0 – 140 mA
Display Size	6.5 inches
Invasive Pressure Monitoring	Optional
Temperature Monitoring	Optional
Wireless Connectivity	Wi-Fi, Bluetooth
