Selecting the Temperature Label
9650-001355-01 Rev. M X Series Operator’s Guide 12-5
Selecting the Temperature Label
Through the Temp Parameter Control Panel, you can configure alarms (as described
previously) and select descriptive Temperature channel labels that will appear on the numeric
display and on the trend report:
Figure 12-2 Temp Parameter Control Panel
You can select one of the following labels for each temperature channel:
If you don’t select a label, the Temperature channels appear with the default labels of T1 and
T2.
Source Label Description
ART Arterial temperature probe
CORE Central body temperature or tympanic membrane temperature
probe
ESOPH Esophageal temperature probe
RECT Rectal temperature probe
SKIN Skin temperature probe (surface application)
VEN Ventilator airway temperature probe
NASO Nasopharynx or nasal/oral temperature probe
Temp
Lower Upper
90
100
T1
T2
85
98
5
8
T1 Source Label
T2 Source Label
ǻ7$ODUP
T2 Alarm
T1 Alarm

ZOLL X Series Specifications

General

Type	Defibrillator/Monitor
Display	Color LCD
ECG Monitoring	Yes
Pacing	Yes
SpO2 Monitoring	Yes
NIBP Monitoring	Yes
Defibrillator Type	Biphasic
EtCO2 Monitoring	Optional
Data Storage	Yes
Battery	Rechargeable Lithium-ion
CPR Feedback	Real CPR Help
Energy Selection	1-360 J
Pacing Rate	30 – 180 ppm
Pacing Output	0 – 140 mA
Display Size	6.5 inches
Invasive Pressure Monitoring	Optional
Temperature Monitoring	Optional
Wireless Connectivity	Wi-Fi, Bluetooth
