ZOLL X Series User Manual

Specifications
A-4 www.zoll.com 9650-001355-01 Rev. M
The vertical axis shows the current in amperes (A); the horizontal axis shows the duration of
time in milliseconds (ms).
Figure A-1. Rectilinear Biphasic Waveform at 200 Joules
Figure A-2. Rectilinear Biphasic Waveform at 150 Joules
-40
-30
-20
-10
0
10
20
30
40
024681012
ms
A
25 Ohm
50 Ohm
75 Ohm
100 Ohm
125 Ohm
150 Ohm
175 Ohm
200 Ohm
-30
-20
-10
0
10
20
30
024681012
ms
A
25 Ohm
50 Ohm
75 Ohm
100 Ohm
125 Ohm
150 Ohm
175 Ohm
200 Ohm

ZOLL X Series Specifications

General

Type	Defibrillator/Monitor
Display	Color LCD
ECG Monitoring	Yes
Pacing	Yes
SpO2 Monitoring	Yes
NIBP Monitoring	Yes
Defibrillator Type	Biphasic
EtCO2 Monitoring	Optional
Data Storage	Yes
Battery	Rechargeable Lithium-ion
CPR Feedback	Real CPR Help
Energy Selection	1-360 J
Pacing Rate	30 – 180 ppm
Pacing Output	0 – 140 mA
Display Size	6.5 inches
Invasive Pressure Monitoring	Optional
Temperature Monitoring	Optional
Wireless Connectivity	Wi-Fi, Bluetooth
