Chapter7ServiceConguration
Forbiddenports:
……/*thedisplayofvlan5-vlan4093isomitted*/
VlanId:4094VlanStatus:enabled
VlanName:
VlanMode:Static
Taggedports:1-19
Taggedtrunks:1-15
Untaggedports:
Forbiddenports:
Thefollowingexampleshowsthatdaughtercardisnotadded
withZXR102920/2928.
zte(cfg)#showvlan
VlanType:802.1qvlan
VlanId:1VlanStatus:enabled
VlanName:
VlanMode:Static
Taggedports:
Untaggedports:1-18
Untaggedtrunks:1-15
Forbiddenports:
TotalVlans:1
3.VLANTranslation
CommandFunction
zte(cfg)#setvlan-translation
ingress-port<feport-id>ingress-vlan
<vlan-list>egress-port<geport-id>
egress-vlan<vlan-list>
ThisconguresVLAN
translationfunction
andtherelated
functionalportand
VLAN.
AfterZXR102920/2928addswithPONdaughtercard,the
translationportwilldiscardtheTAGpacketwithouttransla-
tionrule.
WhenZXR102920/2928doesn’taddwithPONdaughtercard,
thetranslationportwillforwardsallpacketsandnotdiscard
anypacket.
4.IGMPSnoopingFunction
AfterZXR102920/2928addingwithPONdaughtercard,add
port-basedmulticastcontrolonthebasisofvlan-basedmulti-
castcontrol.
EPONConfigurationExample
Example
Description
ThisexampledescribeshowtodistributeservicetoONUbyOLT
device,andhowtoviewtheservicecongurationinformationon
ONUdevice.
