Zte ZXR10 2900 Series - Figure 63 IPTV Configuration Example; IPTV Configuration Example

Chapter7ServiceConguration
CommandFunction
zte(cfg-nas)#showiptvclient[{channel
<channel-id>|index<index-id>|mac
<HH.HH.HH.HH.HH.HH>|port<portid>|
vlan<vlanid>}]
Thisdisplaysthe
informationofiptv
client.
zte(cfg-nas)#cleariptvclient[index
<index-id>|mac<HH.HH.HH.HH.HH.HH>|
port<port-id>[vlan<1-4094>]]
Thisdeletesthe
informationofiptv
client.
IPTVConfigurationExample
1.Example1
AsshowninFigure63,port1connectswiththeuseranditis
theorderuserofchannel225.1.1.1.Theuservlanis100.The
multicastvlanis4000.Routersendsdatastreamofmulticast
group225.1.1.1.PCsendsrequestforenteringintochannel
225.1.1.1.
FIGURE63IPTVCONFIGURATIONEXAMPLE
Congurationofswitch:
i.Congurevlan
zte(cfg)#setvlan100addport1
zte(cfg)#setvlan4000addport1，4
zte(cfg)#setvlan100，4000enable
zte(cfg)#setport1pvid100
zte(cfg)#setport4pvid4000
/*IGMPSnooping*/
zte(cfg)#setigmpsnoopingenable
zte(cfg)#setigmpsnoopingaddvlan100，4000
zte(cfg)#setigmpsnoopingfastleaveenable
ii.CongureIPTV
zte(cfg)#confignas
zte(cfg-nas)#iptvcontrolenable
zte(cfg-nas)#iptvcac-ruleenable
iii.Congurerulesonport
zte(cfg-nas)#iptvchannelmvlan4000group225.1.1.1nameCCTV1id1
zte(cfg-nas)#iptvport1servicestart
zte(cfg-nas)#iptvport1control-modechannel
zte(cfg-nas)#iptvport1channelid-list1order
iv.Viewtheconguration
zte(cfg-nas)#showiptvrule
MaxRuleNum:64
CurRuleNum:1
HisRuleNum:1
IdPortVlanMbaseModeServiceCdrOrderPrviewQueryPkgNum
-----------------------------------------------------------
