Chapter4InstallationandDebugging
FIGURE16FIXINGTHESWITCH
1.Cabinet
2.Box
3.Screw
InstallationofCables
Thefollowingcontentsintroducethecabletypes.ZXR10
2920/2928/2952/2936-FIprovidesthefollowingcables.
�Powersupplycables
�Consolecables
�Networkcables
�Opticalbers
InstallingPowerCables
Powercablesareclassiedintothefollowingtwokindsofcables:
ACpowercablesandDCpowercables.
1.ACpowercableinstallation
AnACpowercablelooksthesameasstandardprinterpower
cable,asshowninFigure17.
FIGURE17ACPOWERCABLE
OneendofACpowercableconnectstheACpowersocketof
ZXR102920/2928/2952/2936-FIpowermodule.Anotherend
ofACpowercableconnectsthe220VACpowersocket.
