InstallingtheEquipment
ZXR102920/2928/2952/2936-FIcanbeinstalledondeskorin
19-inchstandardcabinet.
InstallingtheSwitchonDesktop
Whenswitchisplacedondesktop,installfourplasticpads(the
plasticpadsandscrewsarepartoftheaccessories)onbottom
plateofswitch.ItisshowninFigure13
FIGURE13INSTALLINGPLASTICPADS
1.Case2.Pad
InstallingtheSwitchontoaCabinet
Switchcaneitherbeinstalledonadesktoporin19-inchcabinet.
Where,19-inchstandardcabinetcanbeprovidedbytheuser .In
caseZTEcabinetistobeused,pleasereferto19-InchStandard
CondentialandProprietaryInformationofZTECORPORATION23
