Chapter7ServiceConguration
zte(cfg)#setl2pt0x02enable
zte(cfg)#setvlan100enable
zte(cfg)#setvlan100addport1，3
zte(cfg)#setvlan200enable
zte(cfg)#setvlan200addport2，4
zte(cfg)#sholacpaggregator1
/*showtheaggregationstateofswitch2andswitch3inthesystemview*/
Group1
ActorPartner
-------------------------------------------------------
Priority:3276832768
Mac:00.d0.d0.02.00.5400.d0.d0.29.52.06
Key:258258
Ports:2，12，1
Layer3Configuration
Layer3Overview
ZXR102920/2928/2952/2936-FIprovidesafewlayer3functions
fortheremotecongurationandmanagement.Torealizethere-
moteaccess,anIPportmustbeconguredontheswitch.Ifthe
IPportoftheremotecongurationhostandthatoftheswitchare
notinthesamenetworksegment,itisalsonecessarytocongure
thestaticroute.
Staticrouteisasimpleunicastrouteprotocol.Thenext-hopad-
dresstoadestinationnetworksegmentisspeciedbyuser ,where
nexthopisalsocalledgateway.Staticrouteinvolvesdestination
address,destinationaddressmask,next-hopaddress,andegress
interface.Destinationaddressanddestinationaddressmaskde-
scribethedestinationnetworkinformation.Thenext-hopaddress
andegressinterfacedescribethewaythatswitchforwardsdesti-
nationpacket.
ZXR102920/2928/2952/2936-FIallowsaddinganddeletingthe
staticARPtable.ARPtablerecordsmappingrelationshipbetween
IPaddressandMACaddressofeachnodeinsamenetwork.When
sendingIPpackets,switchrstcheckswhetherdestinationIPad-
dressisinthesamenetworksegment.Ifyes,switchchecks
whetherthereisapeerendIPaddressandMACaddressmap-
pingentryinARPtable.
1.Ifyes,switchdirectlysendstheIPpacketstothisMACaddress.
2.IfMACaddresscorrespondingtopeerendIPaddresscannot
befoundinARPtable,anARPRequestbroadcastpacketwill
besenttothenetworktoquerypeerendMACaddress.
Generally,entriesoftheARPtableontheswitcharedynamic.
StaticARPtableentryneedtobeconguredonlywhenthecon-
nectedhostcannotrespondtheARPRequest.
Tocongurethelayer3function,usecommandconfigrouterto
enterintolayer3congurationmoderst.
CondentialandProprietaryInformationofZTECORPORATION169
