Chapter4ServiceConguration
ParameterDescription
any(rst)
Theanykeywordisusedastheabbreviationofthesource0.0.0.0
andthesourcemask0.0.0.0.
<destination-ipaddr>
Destinationnetworkorhostofthetransmittedpacket.Itisa32-bit
IPaddressexpressedindotteddecimalnotation.
<dip-mask>
Destinationmaskusedfordestination.Itisa32-bitIPaddress
expressedindotteddecimalnotation.
any(second)
Theanykeywordisusedastheabbreviationofthedestination
0.0.0.0andthedestinationmask0.0.0.0
dscp<0-63>
ThisruleisonlyvalidformessageswiththespeciedDSCP
value.Ignorethisruleforothermessages.TherangeofDSCP
valueis0to63.
fragment
Thisruleisonlyvalidforfragmentmessages.Fornon-fragment
messages,thisruleisignored.
cos<0-7>
Thisruleisonlyvalidforthecos-speciedmessage.Ignorethis
ruleforothermessages.Therangeofcosis0to7.
<vlan-id>
ThisruleisonlyvalidformessageswiththespeciedVLANID.
Ignorethisruleforothermessages.TheruleofVLANIDis1
to4094.
<vlan-mask>OptionalVLANmask.Thedefaultvalueis0xfff.
<source-mac>SourceMACaddressofthetransmittedpacket.
<smac-mask>SourceMACmask.
any(third)
TheanykeywordisusedastheabbreviationofthesourceMAC
address00.00.00.00.00.00andthemask00.00.00.00.00.00.
<dest-mac>DestinationMACaddressofthetransmittedpacket.
<dmac-mask>DestinationMACaddressofthetransmittedpacket.
any(fourth)
Theanykeywordisusedastheabbreviationofthedestination
MACaddress00.00.00.00.00.00andthemask00.00.00.00.00.00.
Guidelines
IPrulecanmatchIPv4–speciedprotocoleld,source-speciedIP,anysourceIP ,
destination-speciedIP,anydestinationIP ,DSCPeld,IPfragmenteld,coseld,
VLANeld,source-speciedMAC,anysourceMAC,destination-speciedMACandany
destinationMAC.
4.13.28ingress-aclhybridruletype-tcp
Purpose
ThiscommandsetstherulethatthehybridingressACLmatchestheIPv4-TCPpacket.
