None of the LEDs are on if the VMG is not receiving power.
Table 2 LED Descriptions
LED COLOR STATUS DESCRIPTION
Power Green On The VMG is receiving power and ready for use.
Blinking The VMG is self-testing.
Red On The VMG detected an error while self-testing, or there is a device
malfunction.
Blinking The VMG is upgrading firmware.
Off The VMG is not receiving power.
DSL Green On The VDSL line is up.
Slow
Blinking
The VMG is detecting carrier signals.
Fast
Blinking
The VMG is initializing the VDSL line.
Orange On The ADSL line is up.
Slow
Blinking
The VMG is detecting carrier signals.
Fast
Blinking
The VMG is initializing the ADSL line.
Off The DSL line is down.
Internet Green On The VMG has an IP connection but no traffic.
Your device has a WAN IP address (either static or assigned by a DHCP
server), PPP negotiation was successfully completed (if used) and the DSL
connection is up.
Blinking The VMG is sending or receiving IP traffic.
Off There is no Internet connection or the gateway is in bridged mode.
Red On The VMG attempted to make an IP connection but failed. Possible causes
are no response from a DHCP server, no PPPoE response, PPPoE
authentication failed.
WAN Green On The VMG has a successful 10/100/1000 Mbps Ethernet connection on the
WAN.
Blinking The VMG is sending or receiving data to/from the WAN at 10/100/1000
Mbps.
Off There is no Ethernet connection on the WAN.
LAN1~4 Green On The VMG has a successful 10/100/1000 Mbps Ethernet connection with a
device on the Local Area Network (LAN).
Blinking The VMG is sending or receiving data to/from the LAN at 10/100/1000
Mbps.
Off The VMG does not have an Ethernet connection with the LAN.
WLAN/WPS Green On The 2.4 GHz or 5 GHz wireless network is activated.
Blinking The VMG is communicating with 2.4 GHz or 5 GHz wireless clients.
Orange Blinking The VMG is setting up a WPS connection with a 2.4 GHz or 5 GHz wireless
client.
Off The 2.4 GHz or 5 GHz wireless network is not activated.
