Chapter 22 Voice
VMG8924-B10D/B30D User’s Guide
231
22.9 The Call Summary Screen
The VMG logs calls from or to your SIP numbers. This screen allows you to view the summary of received,
dialed and missed calls.
Click VoIP > Call History > Call Summary. The following screen displays.
Figure 135 VoIP > Call History > Call Summary
Each field is described in the following table.
22.10 Technical Reference
This section contains background material relevant to the VoIP screens.
Type This displays the type of the calls.
Date
This displays the date when the calls were made.
Name This displays the SIP account you called.
Number
This displays the SIP number you called.
Phone Device This field displays the name of a phone port on the VMG.
Outgoing Number This displays how many calls originated from you that day.
Duration
(hh:mm:ss)
This displays how long the current call has lasted.
Modify
Click the Delete icon to remove the call history.
Export Click Export to download a call history list.
Table 107 VoIP > Call History > Call History
LABEL DESCRIPTION
Table 108 VoIP > Call History > Call Summary
LABEL DESCRIPTION
Refresh Click this button to renew the call history list.
Clear All Click this button to remove all entries from the call history list.
Date This is the date when the calls were made.
Total Calls This displays the total number of calls from or to your SIP numbers that day.
Outgoing Calls This displays how many calls originated from you that day.
Incoming Calls This displays how many calls you received that day.
Missing Calls
This displays how many incoming calls were not answered that day.
Total Duration
(hh:mm:ss)
This displays how long all calls lasted that day.
