Chapter 2 The Web Configurator
VMG8924-B10D/B30D User’s Guide
27
2.2.2 Navigation Panel
Use the menu items on the navigation panel to open screens to configure VMG features. The following
tables describe each menu item.
Table 5 Navigation Panel Summary
LINK TAB FUNCTION
Connection Status This screen shows the network status of the VMG and computers/devices
connected to it.
Network Setting
Broadband Broadband Use this screen to view and configure ISP parameters, WAN IP address
assignment, and other advanced properties. You can also add new
WAN connections.
Cellular Backup Use this screen to configure 3G WAN connection.
Advanced Use this screen to enable or disable PTM over ADSL, Annex M/Annex J,
and DSL PhyR functions.
Wireless General Use this screen to configure the wireless LAN settings and WLAN
authentication/security settings.
Guest/More AP Use this screen to configure multiple BSSs on the VMG.
MAC
Authentication
Use this screen to block or allow wireless traffic from wireless devices of
certain SSIDs and MAC addresses to the VMG.
WPS Use this screen to configure and view your WPS (Wi-Fi Protected Setup)
settings.
WMM Use this screen to enable or disable Wi-Fi MultiMedia (WMM).
Others Use this screen to configure advanced wireless settings.
Channel Status Use this screen to scan wireless LAN channel noises and view the results.
Home
Networking
LAN Setup Use this screen to configure LAN TCP/IP settings, and other advanced
properties.
Static DHCP Use this screen to assign specific IP addresses to individual MAC
addresses.
UPnP Use this screen to turn UPnP and UPnP NAT-T on or off.
Additional
Subnet
Use this screen to configure IP alias and public static IP.
STB Vendor ID Use this screen to configure the Vendor IDs of the connected Set Top Box
(STB) devices, which have the VMG automatically create static DHCP
entries for the STB devices when they request IP addresses.
Wake on Lan Use this screen to remotely turn on a device on the local network.
TFTP Server Name Use DHCP option 66 to identify a TFTP server name.
Routing Static Route Use this screen to view and set up static routes on the VMG.
DNS Route Use this screen to forward DNS queries for certain domain names through
a specific WAN interface to its DNS server(s).
Policy Route
Use this screen to configure policy routing on the VMG.
RIP Use this screen to configure Routing Information Protocol to exchange
routing information with other routers.
