Chapter 22 Voice
VMG8924-B10D/B30D User’s Guide
228
Each field is described in the following table.
22.5.1 The Phone Device Edit Screen
Use this screen to control which SIP account and PSTN line each phone uses. Click an Edit icon in the
VoIP > Phone > Phone Device to open the following screen.
Figure 131 VoIP > Phone > Phone Device > Edit
Each field is described in the following table.
Table 103 VoIP > Phone > Phone Device
LABEL DESCRIPTION
# This displays the index number of the phone device.
Phone ID This field displays the name of a phone port on the VMG.
Internal Number This field displays the internal call prefix of a phone port on the VMG.
Incoming SIP
Number
This field displays the SIP number that you use to receive calls on this phone port.
Outgoing SIP
Number
This field displays the SIP number that you use to make calls on this phone port.
Modify
Click the Edit icon to configure the SIP account.
Table 104 VoIP > Phone > Phone Device > Edit
LABEL DESCRIPTION
SIP Account to
Make Outgoing
Call
Select the SIP account you want to use when making outgoing calls with the analog phone
connected to this phone port.
SIP Account(s) to
Receive Incoming
Call
Select a SIP account if you want to receive phone calls for the selected SIP account on this
phone port.
If you select more than one SIP account for incoming calls, there is no way to distinguish
between them when you receive phone calls. If you do not select a source for incoming calls,
you cannot receive any calls on this phone port.
