Chapter 6 Broadband
VMG8924-B10D/B30D User’s Guide
81
6.3 The Cellular Backup Screen
The USB port (at the side panel of the VMG) allows you to attach a cellular dongle to wirelessly connect
to a cellular network for Internet access. You can have the VMG use the cellular WAN connection as a
backup. Disconnect the DSL and Ethernet WAN ports to use the cellular dongle as your primary WAN
connection. The VMG automatically uses a wired WAN connection when available.
Figure 25 Internet Access Application: Cellular WAN
Use this screen to configure your cellular settings. Click Network Setting > Broadband > Cellular Backup.
Service
Category
Select UBR Without PCR for applications that are non-time sensitive, such as e-mail.
Select CBR (Continuous Bit Rate) to specify fixed (always-on) bandwidth for voice or data traffic.
Select Non Realtime VBR (non real-time Variable Bit Rate) for connections that do not require
closely controlled delay and delay variation.
Select Realtime VBR (real-time Variable Bit Rate) for applications with bursty connections that
require closely controlled delay and delay variation.
VLAN This section is available only when you select ADSL/VDSL over PTM in the Type field.
Active Select Enable to activate VLAN on this WAN interface. Otherwise, select Disable to deactivate.
802.1p IEEE 802.1p defines up to 8 separate traffic types by inserting a tag into a MAC-layer frame that
contains bits to define class of service.
Select the IEEE 802.1p priority level (from 0 to 7) to add to traffic through this connection. The
greater the number, the higher the priority level.
802.1q Type the VLAN ID number (from 0 to 4094) for traffic through this connection.
OK Click OK to save your changes.
Cancel Click Cancel to exit this screen without saving.
Table 12 Network Setting > Broadband > Add New WAN Interface/Edit (ADSL over ATM-Bridge Mode)
LABEL DESCRIPTION
