Chapter 1 Introducing the VMG
VMG8924-B10D/B30D User’s Guide
20
Figure 5 VMG8924-B10D Front and Side Panels
The following table describes the items on the side panels..
1.6 LEDs (Lights)
The following graphic displays the labels of the LEDs.
Figure 6 LEDs on the VMG
Table 1 Side Panel Buttons
LABEL DESCRIPTION
WLAN Press the WLAN button for more than two seconds to enable the wireless
function.
WPS Press the WPS button for more than five seconds to quickly set up a secure
wireless connection between the device and a WPS-compatible client.
USB The USB port is used for cellular WAN backup, file-sharing and media server.
