VMG8924-B10D/B30D User’s Guide
251
CHAPTER 25
VoIP Status
25.1 The VoIP Status Screen
Click System Monitor > VoIP Status to open the following screen. You can view the VoIP registration,
current call status and phone numbers in this screen.
Figure 146 System Monitor > VoIP Status
The following table describes the fields in this screen.
Table 121 System Monitor > VoIP Status
LABEL DESCRIPTION
Poll Interval(s) Enter the number of seconds the VMG needs to wait before updating this screen and then click
Set Interval. Click Stop to have the VMG stop updating this screen.
SIP Status
Account This column displays each SIP account in the VMG.
Registration This field displays the current registration status of the SIP account. You can change this in the
Status screen.
Registered - The SIP account is registered with a SIP server.
Not Registered - The last time the VMG tried to register the SIP account with the SIP server, the
attempt failed. The VMG automatically tries to register the SIP account when you turn on the
VMG or when you activate it.
Inactive - The SIP account is not active. You can activate it in VoIP > SIP > SIP Account.
Registration
Time
This field displays the last time the VMG successfully registered the SIP account. The field is blank
if the VMG has never successfully registered this account.
URI This field displays the account number and service domain of the SIP account. You can change
these in the VoIP > SIP screens.
Message
Waiting
This field indicates whether or not there are any messages waiting for the SIP account.
Last Incoming
Number
This field displays the last number that called the SIP account. The field is blank if no number has
ever dialed the SIP account.
