Chapter 2 The Web Configurator
VMG8924-B10D/B30D User’s Guide
29
SIP SIP Account Use this screen to set up information about your SIP account and
configure audio settings such as volume levels for the phones
connected to the VMG.
SIP Service
Provider
Use this screen to configure the SIP server information, QoS for VoIP calls,
the numbers for certain phone functions, and dialing plan.
Phone Phone Device
Use this screen to view detailed information of the phone devices.
Region
Use this screen to select your location and a call service mode.
Call Rule Speed Dial
Use this screen to configure speed dial for SIP phone numbers that you
call often.
Call History Call History Use this screen to view a call history list.
Call Summary Use this screen to view the summary of received, dialed and missed calls.
System Monitor
Log System Log Use this screen to view the status of events that occurred to the VMG.
You can export or e-mail the logs.
Security Log Use this screen to view all security related events. You can select level
and category of the security events in their proper drop-down list
window.
Levels include:
•Emergency
•Alert
• Critical
• Error
• Warning
•Notice
• Informational
•Debugging
Categories include:
• Account
• Attack
•Firewall
• MAC Filter
Traffic Status WAN Use this screen to view the status of all network traffic going through the
WAN port of the VMG.
LAN Use this screen to view the status of all network traffic going through the
LAN ports of the VMG.
NAT Use this screen to view NAT statistics for connected hosts.
VoIP Status VoIP Status Use this screen to view VoIP registration, current call statust and phone
numbers for the phone ports.
ARP table ARP table Use this screen to view the ARP table. It displays the IP and MAC address
of each DHCP connection.
Routing Table Routing Table Use this screen to view the routing table on the VMG.
Multicast Status IGMP Status Use this screen to view the status of all IGMP settings on the VMG.
MLD Status Use this screen to view the status of all MLD settings on the VMG.
xDSL Statistics xDSL Statistics Use this screen to view the VMG’s xDSL traffic statistics.
Cellular
Statistics
Cellular Statistics Use this screen to look at cellular Internet connection status.
Maintenance
Table 5 Navigation Panel Summary (continued)
LINK TAB FUNCTION
