IP Address This field displays the current IP address of the VMG in the WAN.
IP Subnet Mask This field displays the current subnet mask in the WAN.
MAC Address This shows the WAN Ethernet adapter MAC (Media Access Control) Address of your VMG.
Primary DNS
server
This field displays the first DNS server address assigned by the ISP.
Secondary DNS
server
This field displays the second DNS server address assigned by the ISP.
DHCP This field displays whether the WAN interface is using a DHCP IP address or a static IP address.
Choices are:
Client - The WAN interface can obtain an IP address from a DHCP server.
None - The WAN interface is using a static IP address.
LAN Information
IP Address This is the current IP address of the VMG in the LAN.
IP Subnet Mask This is the current subnet mask in the LAN.
IPv6 Link Local
Address
This field displays the current link-local address of the VMG for the LAN interface.
DHCP This field displays what DHCP services the VMG is providing to the LAN. The possible values
are:
Server - The VMG is a DHCP server in the LAN. It assigns IP addresses to other computers in
the LAN.
Relay - The VMG acts as a surrogate DHCP server and relays DHCP requests and responses
between the remote server and the clients.
None - The VMG is not providing any DHCP services to the LAN.
MAC Address This shows the LAN Ethernet adapter MAC (Media Access Control) Address of your VMG.
WLAN 2.4G/5G Information
MAC Address This shows the wireless adapter MAC (Media Access Control) Address of the wireless
interface.
Status This displays whether the WLAN is activated.
SSID This is the descriptive name used to identify the VMG in a wireless LAN.
Channel This is the channel number used by the wireless interface now.
Security This displays the type of security mode the wireless interface is using in the wireless LAN.
802.11 Mode This displays the type of 802.11 mode the wireless interface is using in the wireless LAN.
WPS This displays whether WPS is activated on the wireless interface.
Security
Firewall This displays the firewall’s current security level.
System Status
System Up Time This field displays how long the VMG has been running since it last started up. The VMG starts
up when you plug it in, when you restart it (Maintenance > Reboot), or when you reset it.
Current Date/
Time
This field displays the current date and time in the VMG. You can change this in
Maintenance> Time Setting.
System Resource
CPU Usage This field displays what percentage of the VMG’s processing ability is currently used. When
this percentage is close to 100%, the VMG is running at full load, and the throughput is not
going to improve anymore. If you want some applications to have more throughput, you
should turn off other applications (for example, using QoS; see Chapter 10 on page 142).
Table 7 Status Screen (continued)
