Installation stages
Kit ordering codeKit codeInstruction codeInstallation stage#
Common parts:1
--3AXD50000336340Baying parts
--3AXD50000336104PE busbar
--3AXD50000336692Divider panel
3AXD50000333387A-468-X-001-VX3AXD50000333639DC busbars
DC connection 1 of 2 (from DC bus to
DC fuses) without DC switch/charging:
2 A
3AXD50000337415A-4-8-252-VX3AXD50000345151Busbar assembly
3AXD50000337446A-46-8-206-VX3AXD50000345915Busbars
DC connection 1 of 2 (from DC bus to
DC fuses) with DC switch/charging:
2 B
3AXD50000337439A-4-8-288-VX3AXD50000342501DC switch/charging mechanics
3AXD50000337422A-4-8-290-VX3AXD50000345236Busbar assembly
3AXD50000337453A-46-8-207-VX3AXD50000345458Busbars
Module mechanical installation parts,
lead-throughs:
3
3AXD50000337071A-4-8-310-VX3AXD50000335152Module top/bottom guides
3AXD50000004385A-468-8-4413AXD50000004817Lead-throughs
Quick connector, output (AC) busbars
(cable connection):
4 A
3AUA0000119227A-468-8-1003AUA0000118667Quick connector
3AXD50000337477A-4-8-132-VX3AXD50000343492Busbars and shrouds
Quick connector, output (AC) busbars
(common AC output busbar connec-
tion):
4 B
3AUA0000119227A-468-8-1003AUA0000118667Quick connector
3AXD50000337088A-4-8-140-VX3AXD50000343928Busbars and shrouds
DC connection 2 of 2 (from DC fuses
to inverter module) without DC
switch/charging:
5 A
3AXD50000028403A-468-8-2463AXD50000028384DC connection flanges
3AXD50000028401A-468-8-2353AXD50000028418DC busbars with common mode filters
(filters not included in kit)
DC connection 2 of 2 (from DC fuses
to inverter module) with DC
switch/charging:
5 B
3AXD50000044553A-468-8-2483AXD50000043466DC connection flanges
3AXD50000044551A-468-8-2473AXD50000043411DC busbars with common mode filters
(filters not included in kit)
3AXD50000337484A-4-8-359-VX3AXD50000335169Shrouding6
---Inverter module7
Cabinet construction 111
