￭ Three R8i modules in a 800 mm wide generic enclosure
Kit ordering codeKit codeInstruction codeParts installed
3AXD50000044581A-8-8-2943AXD50000044586DC switch/charging mechanics (optional)
DC busbars (without DC switch/charging):
3AXD50000006450A-8-8-2583AXD50000006455Busbar assembly
3AXD50000028401A-468-8-2353AXD50000028418DC busbars with common mode filters (fil-
ters not included in kit)
3AXD50000028403A-468-8-2463AXD50000028384DC connection flanges
DC busbars (with DC switch/charging):
3AXD50000044584A-8-8-2973AXD50000044574Busbar assembly
3AXD50000044551A-468-8-2473AXD50000043411DC busbars with common mode filters (fil-
ters not included in kit)
3AXD50000044553A-468-8-2483AXD50000043466DC connection flanges
Module mechanical installation parts, lead-
throughs:
3AXD50000005877A-8-8-3123AXD50000005848Module top/bottom guides
3AXD50000004385A-468-8-4413AXD50000004817Lead-throughs
Quick connector, output (AC) busbars:
3AUA0000119227A-468-8-1003AUA0000118667Quick connector
3AXD50000006492A-8-8-1373AXD50000006503Busbars and shrouds (without bridging)
3AXD50000006494A-8-8-1393AXD50000006498Busbars and shrouds (with bridging)
---Inverter module
---Shrouding
Cabinet construction 141
