Output ratings
Input
ratings
Frame
size
Inverter
unit
type
ACS880-
104- …
Heavy-duty use
Light-overload
use
No-overload use
P
Hd
I
Hd
P
Ld
I
Ld
S
N
P
N
I
2
I
max
I
1
kWAkWAkVAkWAAA
710770900989123110001030155011592×R8i1030A-7
80087510001123139811001170176013162×R8i1170A-7
1100115214001478184014001540231017333×R8i1540A-7
1200130216001670208016001740261019583×R8i1740A-7
1600172020002208274920002300345025884×R8i2300A-7
2000213924002746341828002860429032185×R8i2860A-7
2400255832003283408732003420513038486×R8i3420A-7
￭ Definitions
Nominal AC supply voltage of drive system
U
N
Nominal rms input current
I
1
Nominal output current (available continuously with no over-loading)
I
2
Typical motor power in no-overload use
P
N
The horsepower ratings are typical NEMA motor sizes at 460 V (ACS880-104-xxxxA-5) and 575 V
(ACS880-104-xxxxA-7) respectively.
Apparent power in no-overload use
S
N
Continuous rms output current allowing 10% overload for 1 minute every 5 minutes
I
Ld
Typical motor power in light-overload use
P
Ld
Maximum output current. Available for 10 seconds at start; otherwise as long as allowed by drive
temperature.
I
max
Continuous rms output current allowing 50% overload for 1 minute every 5 minutes
I
Hd
Typical motor power in heavy-duty use
P
Hd
Note:
• The ratings apply at an ambient temperature of 40 °C (104 °F).
• The ratings apply to units without option +C132 (marine type approval). For ratings of
units with option +C132, see ACS880 +C132 marine type-approved drive modules and
module packages supplement (3AXD50000037752 [English])
• To achieve the rated motor power given in the table, the rated current of the drive must
be higher than or equal to the rated motor current.
• The DriveSize dimensioning tool available from ABB is recommended for selecting the
drive, motor and gear combination.
278 Technical data
