￭ Mersen PS272PREMCPS (N220076) fuse disconnector (for R5i, 27 ×
60 mm fuses)

4
2
1
57
14
20
4
2
1
35
46
24
Y
71
107
146
180
15
V
ø6.5
2.5
7.5
ø11.5
Z
Z'
W
W'


1
2
Twin terminal covers1.
PS 27
Part #: A 220087
Weight: 30 g
Packaging: 3 twins
MC PS2.
93 Connecting distance between centersV:
150 Without terminals cover lengthW:
240 With terminals cover lengthW′:
196 Space factor with a 90° fuse carrier positionY:
284 Without terminal cover, space factor with a 180° fuse carrier positionZ:
279 With terminal cover, space factor with a 180° fuse carrier positionZ′:
Dimension drawings 357
