DC bus installation parts (for Rittal VX25 enclosures)
The brackets in this kit act as a mounting base for the busbar supports of the Rittal Flat-PLS
DC bus and ensure its correct placement and alignment inside the cabinet line-up.
Note:
The designs presented in this manual for Rittal VX25 enclosures employ the Rittal Flat-PLS
busbar system. Make sure that the current carrying capability of the busbars is not exceeded
at any point of the drive system.
IllustrationKit codeOrdering codeQtyUsed with …
A-468-X-001-
VX
3AXD50000333387
1 kit per cu-
bicle
400/600/800 mm VX25
enclosure
Instruction code:
3AXD50000333639
DC connection parts 1 of 2 (for Rittal VX25 enclosures)
These parts connect the Flat-PLS busbars to the DC fuses, and provide the mounting base
for the charging components if required.
IllustrationKit codeOrdering codeQtyUsed with…
A-46-8-206-VX3AXD50000337446
1 per
mod-
ule
400/600 mm VX25 enclosure
without DC switch/disconnect-
or and charging
Instruction code:
3AXD50000345915
