ABB ACS880-104

￭ Cooling fans (frames R1i…R4i)
One or two cooling fans are to be installed inside the air outlet compartment to ensure
sufficient cooling of the cabinet.
IEC
Ordering codeQty
ComponentEnclosure width / Degree of
protection
(Auxiliary voltage)
DataName
3AXD500000005921R3G225-RH17-23Fan
400 mm, 600 mm / IP20, IP42
(230 V 50/60 Hz)
3AXD500000007231SPB2,5/7 (2.5 mm
2
, 12AWG)Connector
3AXD500000007241
SC 2,5-RZ/7 (2.5 mm
2
,
12AWG)
Connector
3AXD500000069341RB4C-355/170Fan
400 mm / IP54
(230 V 50/60 Hz)
3AXD500000069591MSB MKP 6/603/E1679Capacitor
3AXD500000007231SPB2,5/7 (2.5 mm
2
, 12AWG)Connector
3AXD500000007241
SC 2,5-RZ/7 (2.5 mm
2
,
12AWG)
Connector
3AXD500000061111CRBB/4-400/188Fan
600 mm / IP54
(230 V 50/60 Hz)
3AXD500000068851MSB MKP 12/603/E1679Capacitor
3AXD500000007231SPB2,5/7 (2.5 mm
2
, 12AWG)Connector
3AXD500000007241
SC 2,5-RZ/7 (2.5 mm
2
,
12AWG)
Connector
3AXD500000005922R3G225-RH17-23Fan
800 mm / IP20, IP42
(230 V 50/60 Hz)
3AXD500000007232SPB2,5/7 (2.5 mm
2
, 12AWG)Connector
3AXD500000007242
SC 2,5-RZ/7 (2.5 mm
2
,
12AWG)
Connector
3AXD500000069342RB4C-355/170Fan
800 mm / IP54
(230 V 50/60 Hz)
3AXD500000069592MSB MKP 6/603/E1679Capacitor
3AXD500000007232SPB2,5/7 (2.5 mm
2
, 12AWG)Connector
3AXD500000007242
SC 2,5-RZ/7 (2.5 mm
2
,
12AWG)
Connector
UL
Ordering codeQty
ComponentEnclosure width / Degree of
protection
(Auxiliary voltage)
DataName
3AXD500000005141R2E225-RA92-17Fan
400 mm, 600 mm / IP20, IP42
(230 V 50/60 Hz)
3AXD500000008821MSB MKP 3,5/603/E1679Capacitor
3AXD500000007231SPB2,5/7 (2.5 mm
2
, 12AWG)Connector
3AXD500000007241
SC 2,5-RZ/7 (2.5 mm
2
,
12AWG)
Connector
685029261R2E225-BD40-65Fan
400 mm, 600 mm / IP20, IP42
(115 V 60 Hz)
589152111KO230F, mod. 345Capacitor
3AXD500000007231SPB2,5/7 (2.5 mm
2
, 12AWG)Connector
3AXD500000007241
SC 2,5-RZ/7 (2.5 mm
2
,
12AWG)
Connector
268 Ordering information
