ABB ACS880-104

Installation stages
Kit ordering codeKit codeInstruction codeInstallation stage#
Common parts:1
--3AXD50000336340Baying parts
--3AXD50000336104PE busbars
--3AXD50000336692Divider panel
3AXD50000333387A-468-X-001-VX3AXD50000333639DC bus support kit
---Bottom plate2
--3AXD50000444588Mounting plate (IEC)3
--3AXD50000003890Mounting plate (UL)
3AXD50000474493A-4-1234-272-VX3AXD50000453108DC busbars (IEC)4
3AXD50000003918A-4-1234-2743AXD50000003895DC busbars (UL)
3AXD50000456772A-4-1234-403-VX3AXD50000450060Mounting plate shrouds5
Inverter modules and air guides:6
3AUA0000114398A-468-1-4223AUA0000114397R1i
3AUA0000114330A-468-2-4233AUA0000114397R2i
3AUA0000114404A-468-3-4243AUA0000114397R3i
3AUA0000114405A-468-4-4253AUA0000114397R4i
See AC-side compon-
ents (page 212)
-3AXD50000458721du/dt filters7
