Definitions
Maximum continuous braking power. The braking is considered continuous if the braking time exceeds
30 seconds.
P
brcont
Maximum braking power of the inverter module and its internal brake chopper. The inverter and
chopper will withstand this braking power for 1 second within every 10 seconds.
Note:
The listed resistors will withstand this braking power for 1 second within every 120 seconds.
P
brmax
Minimum allowed resistance of the brake resistor.
R
min
Resistance of the listed resistor.
R
Continuous power (heat) dissipation of the listed resistor when placed correctly.
P
n
Short energy pulse that the listed resistor will withstand every 400 seconds.
E
R
The ratings apply at an ambient temperature of 40 °C (104 °F).
The listed brake resistors are protected to IP20. Refer to Resistor dimensions (page 337) for
dimensions, wire sizes and tightening torques for the resistors.
