￭ Two R8i modules in a 600 mm wide Rittal VX25 enclosure
3
5
2
1
5
With DC switch/
disconnector and
charging
Without DC switch/
disconnector and
charging
2
44
5
5
Description
Cubicle including:
1. DC switch/disconnector (obscured)
2. DC fuses
3. Charging switch
4. Common mode filters
5. Inverter module
Cabinet construction 123
