ABB ACS880-104

Input power (DC) connection
ACS880-104-xxxxx-3: 513…566 V DC. This is indicated in the type designation
label as typical input voltage level (566 V DC).
Voltage (U
1
)
ACS880-104-xxxxx-5: 513…707 V DC. This is indicated in the type designation
label as typical input voltage levels (566/679/707 V DC).
ACS880-104-xxxxx-7: 709…976 V DC. This is indicated in the type designation
label as typical input voltage levels (742/849/976 V DC).
TN (grounded) and IT (ungrounded) systems up to 690 V AC, corner-grounded
systems up to 600 V AC
Drive AC supply network
type
Frame R1iInput terminals
UDC+, UDC–: 0.25…4 mm
2
, 0.5 … 0.6 N·m (4.4 …5.3 lbf·in)
PE: 1.5 N·m (13 lbf·in)
Frame R2i
UDC+, UDC–: 0.5 … 6 mm
2
, 1.2 … 1.5 N·m (10.6 … 13.3 lbf·in)
PE: 1.5 N·m (13 lbf·in)
Frames R3i, R4i and R5i
UDC+, UDC–: 6…70 mm
2
. Allen screw torque 15 N·m (11 lbf·ft), connection post
torque 4 N·m (30 lbf·in). Other conductor sizes can be used by replacing the original
lug with a suitable crimp ring terminal.
PE: Screw size M5, torque 3 N·m (25 lbf·in)
Connector cover screws: Torque 3 N·m (25 lbf·in)
Frames R6i and R7i
See chapter Dimension drawings (page 339), and section One R6i/R7i module in
a 400 mm wide Rittal VX25 enclosure (page 97)
Frame R8i and multiples
M12, maximum intrusion into module 20 mm (0.8”). See also chapter Dimension
drawings (page 339), and section One R8i module in a 400 mm wide Rittal VX25
enclosure (page 110)
Motor (AC) connection
Asynchronous AC induction motors, permanent magnet synchronous motors and
AC induction servomotors
Motor types
3-phase symmetrical, Umax at field weakening point:
Voltage (U
2
)
ACS880-104-xxxxx-3: 0…400 V AC. The maximum value (400 V) is a typical drive
input voltage level shown on the type designation label of the supply unit corres-
ponding to 380…415 V AC.
ACS880-104-xxxxx-5: 0…400/480/500 V AC. The maximum values (400/480/500
V) are typical drive input voltage levels shown on the type designation label of the
supply unit corresponding to 380…500 V AC.
ACS880-104-xxxxx-7: 0…525/600/690 V AC. The maximum values (525/600/690
V) are typical drive input voltage levels shown on the type designation label of the
supply unit corresponding to 525…690 V AC.
0…500 Hz, exceptFrequency (f
2
)
0…120 Hz with sine output filters (option +E206)
0…120 Hz for frames R1i…R5i with du/dt filters (option +E205)
0…200 Hz for frames R6i and R7i with du/dt filters (option +E205)
For higher operational output frequencies, please contact your local ABB repres-
entative.
Operation above 150 Hz may require type-specific derating. For more information,
contact your local ABB representative.
Technical data 287
