ABB ACS880-104

Installation stages
Kit ordering codeKit codeInstruction codeInstallation stage#
Common parts:1
--3AXD50000336340Baying parts
--3AXD50000336104PE busbars
--3AXD50000336692Divider panel
3AXD50000333387A-468-X-001-VX3AXD50000333639DC busbars
---Bottom plate2
--3AXD50000452934Support beams3
DC busbars and charging components:4
3AXD50000459094A-4-67-283-VX3AXD50000444489R6i without DC switch
3AXD50000459100A-4-6-281-VX3AXD50000445202R6i with DC switch (IEC)
3AXD50000459117A-4-6-285-VX3AXD50000445325R6i with DC switch (UL)
3AXD50000459094A-4-67-283-VX3AXD50000444489R7i without DC switch or charging
3AXD50000459063A-4-7-282-VX3AXD50000445097R7i without DC switch, with charging
3AXD50000459056A-4-7-280-VX3AXD50000445257R7i (400/500 V) with DC switch and
charging
3AXD50000459070A-4-7-286-VX3AXD50000445356R7i (690 V) with DC switch and char-
ging
3AXD50000459087A-4-7-287-VX3AXD50000445332R7i (690 V) without DC switch, with
charging
3AXD50000458509A-4-67-241-VX3AXD50000444304Common mode filters (filters not in-
cluded in kit)
5
3AXD50000459032A-4-67-181-VX3AXD50000452798AC busbars without output (du/dt) fil-
ters
6 A
3AXD50000459049A-4-67-186-VX3AXD50000452439AC busbars with output (du/dt) filters6 B
3AXD50000459018A-4-67-302-VX3AXD50000453337Inverter module installation parts7
3AXD50000458493A-4-67-350-VX3AXD50000453252Shroud brackets8
98 Cabinet construction
4
