ABB ACS880-104

Modules usedInverter unit
Ordering code
(for options, see below)
QtyFrame sizeType
ACS880-104-0410A-7 +E2051R8iACS880-104-0410A-7
ACS880-104-0530A-7 +E2051R8iACS880-104-0530A-7
ACS880-104-0600A-7 +E2051R8iACS880-104-0600A-7
ACS880-104-0410A-7 +E20522×R8iACS880-104-0800A-7
ACS880-104-0530A-7 +E20522×R8iACS880-104-1030A-7
ACS880-104-0600A-7 +E20522×R8iACS880-104-1170A-7
ACS880-104-0530A-7 +E20533×R8iACS880-104-1540A-7
ACS880-104-0600A-7 +E20533×R8iACS880-104-1740A-7
ACS880-104-0600A-7 +E20544×R8iACS880-104-2300A-7
ACS880-104-0600A-7 +E20555×R8iACS880-104-2860A-7
ACS880-104-0600A-7 +E20566×R8iACS880-104-3420A-7
Option codesOrdering code format
+C132: Marine type approval. For more information, see ACS880 +C132
marine type-approved drive modules and module packages supplement
(3AXD50000037752 [English]).
[Module type] +code [+code] …
For example,
ACS880-104-0470A-3 +E205
+C183: Heating element mounted to module base
+C188: Direct-on-line (DOL) cooling fan
+E205: Internal du/dt filtering. Standard with 690 V modules, required
with parallel-connected modules for all nominal voltages
+G304: 115 V AC auxiliary voltage supply
+P942: Mechanical compatibility with ACS800 R8i.
Note:
The following components are also required to construct a working inverter unit and must
be ordered separately:
• An ACS-AP-x control panel is required for the commissioning of an ACS880 drive
system, even if the Drive composer PC tool is used. See section ACS-AP-W control
panel below.
• Inverter control unit (see section Inverter control unit below)
• Fiber optic cabling from control unit to each inverter module (see section Fiber optic
cables below)
• Common mode filters
• Control circuit plug connectors
• Quick connector.
The other parts listed in this chapter for this frame size
• may be required by the application (such as a DC switch/disconnector), or
• make the installation or use of the module easier.
236 Ordering information
