Each example includes a table that lists:
• installation stages of different equipment in the order in which the installation into the
cabinet should be performed
• code of the step-by-step instructions
• equipment kit code
• kit ordering code.
You can find the kit-specific assembly drawings, step-by-step instructions and kit information
on the Internet. Go to https://sites-apps.abb.com/sites/lvacdrivesengineeringsupport/content.
If needed, contact your local ABB representative.
The example includes also cabinet assembly drawings that show each stage listed in the
table. More detailed steps of each stage are described in the kit-specific assembly drawings.
For general instructions, see Cabinet design and construction instructions for drive modules
(3AUA0000107668 [English]).
46 Cabinet construction
