Section D Graphic Display
D-72
The following attribute designations are used in the system:
When used in dynamic objects, the designators are extended by sequence numbers (usually 1–8
or for objects in a trend window, 1–6) or, for button fields, <column>_<line>.
Attribute
Designator
Object type Meaning
Action BG, FA, AD, SEL, SA, GS,
BUT, BTF
Action which can be triggered by this object
in DigiVis
Background TXT, AD Text background color
Background color,
Foreground color
PIE, ELP, PLG, REC, BG,
FA, SEL
Fill pattern colors
Bit variable_1..3 BG, FA, AD, SA, GS Bit variables which control attribute changes
in the object
Bordercolor,
Fillcolor
SEL Border and fill color of a select field
Bordercolor_1..2,
Fillcolor_1..2
BUT, BTF, BTR Frame (or text) and background color of
buttons
Bordercolor_1..8,
Fillcolor_1..8
BG, FA, SA, GS Colors determined by the bit variables
Caption TXT, CUO, BUT, BTF,
BTR
Static text, for trend window the graph
labeling
Charactersize TXT, AD, BUT Text size: 8, 12, 20 or 26 point
Faceplate_1..6 CUO Tag faceplates assigned to the curves
Fillpattern PIE, ELP, PLG, REC, BG,
FA, SEL
Fill pattern
Line_end ARC, LIN, PLN, Ending end of line: round or with arrow
Line_rounded ARC, LIN, PLG, PLN,
REC, BG, FA, SEL
Rounding of corners
Line_start ARC, LIN, PLN, Starting end of line: round or with arrow
Linecolor ARC, PIE, ELP, LIN, PLG,
PLN, REC, BG, FA
Line color
