Section D Graphic Display
D-73
Attribute
Designator
Object type Meaning
Linestyle ARC, PIE, ELP, LIN, PLG,
PLN, REC, BG, FA, SEL
Type of line: solid or dotted,...
Linewidth ARC, PIE, ELP, LIN, PLG,
PLN, REC, BG, FA, SEL
Line width
Max_Duration CUO Maximum trend collection period
Reference BG, FA Bar graph and fill area reference line
Scale_start,
Scale_end
BG, FA, CUO Scale range for object or curve
Std_Duration CUO Trend display period
Text_alignment TXT Text alignment: top pr bottom
Text_bold TXT, AD, BUT Bold text
Text_direction TXT, AD, BUT Text direction: horizontal or vertical
Text_fixpoint TXT, AD, BUT Text justification: start, center, end
Text_italic TXT, AD, BUT Cursive (italic) text
Text_underlined TXT, AD, BUT Underlined text
Textcolor TXT, AD Text color
Trendcolor_1..6 CUO Curve color
Value BUT, BTR Button value: used for state display and, for
radio buttons, as value to be written
Variable BG, FA, AD, BUT, BTR Display variable
Variable_1..6 CUO Variable for trend monitoring
Windowcolor_1..3 CUO Trend window colors;
1: Background color,
2: Grid and labeling color
3: Graph area background color
