DescriptionRevision
Changes made in this revision
• Flange sealing changed from 12340011-116 Loctite 574 to
3HAC026759-002 Sikaflex-521FC for small cover on the housing,
see Replacing the axis-4 FPC unit, housing extender unit and
housing extender sealings on page 245.
• Tightening torque for attachment screws on lifting accessories is
changed from 40 Nm to 15 Nm.
• Tightening torque for lower arm cable
• Tightening torque for the axis-4 FPC unit attachment screws is
changed from 1.5 Nm to 0.3 Nm.
• Added a tightening torque for the attachment screws of the axis-
1 calibration stop pin and the axis-1 calibration pin.
• Added a caution note to keep a straight line when fitting the axis-
1 calibration pin.
• Article number of grease harmonic grease 4B No. 2 changed from
3HAC031695-001 to 3HAC037302-001.
• Total amount of harmonic grease 4B No.2 for axis 2 and axis 5
changed from 80 g and 12 g to 60 g and 9 g, respectively,
• Maximum revolution of axis 6 corrected to ±242°, see Working
range on page 61.
• Clean Room option added.
• Food grade lubrication option added.
• Spare part numbers for several gaskets (IP67) updated.
• The base, the swing and the axis-1 sealing ring are updated due
to IP67 improvements
C
Published in release R16.2. The following updates are done in this revi-
sion:
• New standard calibration method introduced (Axis Calibration).
See Calibration on page 805.
• Information about grounding point is added, see Grounding and
bonding point on manipulator on page 108.
• Foundry Plus option added.
D
Published in release R17.1. The following updates are done in this revi-
sion:
• A new standard IEC 61340-5-1:2010 added. See Applicable
standards on page 884.
• V-ring on axis-1 sealing ring version 3HAC058568-001 added as
a spare part.
• Notes added for spare part versions. See Description of spare
part versions on page 874.
• Information about Type B robots supporting SafeMove 2 added.
• Plug on base added to options IP67 and Foundry Plus.
E
Continues on next page
Product manual - IRB 1200 13
3HAC046983-001 Revision: S
© Copyright 2014 - 2021 ABB. All rights reserved.
