5.3.4 Replacing the cable grommet assembly
Location
The illustration shows the location of the cable grommet assembly on the controller.
xx2200002163
Note
The end user needs to install proper grommets according to the diameter of the
cables which need to go through the grommet.
Incorrect use of grommets will affect ingress protection, EMI/EMC and
temperature.
It is recommended to use icotek KT grommet.
Required spare parts
Note
The spare part numbers that are listed in the table can be out of date. See the
latest spare parts of the OmniCore V250XT Type B via myABB Business Portal,
www.abb.com/myABB.
NoteArticle numberSpare part
3HAC066396-001Cable grommet asm
3HAC084125-001Harness network connection
2xM12
3HAC084103-001Harness network connection
1xM12
3HAC069954-001Blind plate
3HAC070894-001Harness Ethernet comm. 5xM12
Continues on next page
Product manual - OmniCore V250XT Type B 303
3HAC087112-001 Revision: A
