7 Troubleshooting
7.1 Introduction to troubleshooting
Introduction
The product manual and the circuit diagram contains information that can be good
when troubleshooting.
For OmniCore, all event logs from the software can be seen on the FlexPendant,
or in Technical reference manual - Event logs for RobotWare 7.
Make sure to read through the section Safety on page 13 before starting.
Note
During troubleshooting with power on, the internal fan might cause dust to enter
the cabinet.
CAUTION
During troubleshooting with power on, make sure not to place your head too
close to the internal fan located on the door.
Troubleshooting strategies
1 Isolate the fault to pinpoint the cause of the problem from consequential
problems.
2 Divide the fault chain in two.
3 Check communication parameters and cables.
4 Check that the software version is compatible with the hardware.
Work systematically
1 Take a look around to make sure that all screws, connectors, and cables are
secured, and that the robot and other parts are clean, not damaged, and
correctly fitted.
2 Replace one thing at a time.
3 Do not replace units randomly.
4 Make sure that there are no loose screws, turnings, or other unexpected
parts remaining after work has been performed.
5 When the work is completed, verify that the safety functions are working as
intended.
Keep a track of history
• Make a historical fault log to keep track of problems over time.
• Consult those working with the robot when the problem occurred.
Continues on next page
Product manual - OmniCore V250XT Type B 345
3HAC087112-001 Revision: A
© Copyright 2023-2023 ABB. All rights reserved.
