118 Parameters
177.25 Transformer low oil level
failure logic
Selects failure logic for medium voltage transformer low
oil level. The alarm is active high or active low.
Active High/
List
Active Low 0
Active High 1
177.26 MV overpressure
source
Selects source for medium voltage transformer
overpressure signal.
See also Digital inputs on page 50.
Off/ List
Off 0
On 1
Digital input X20.1 2
Digital input X20.2 3
Digital input X20.3 4
Digital input X20.4 5
Digital input X20.5 6
Digital input X20.6 7
Digital input X20.7 8
Spare DI8 9
Spare DI9 10
Spare DI10 11
Spare DI11 12
Spare DI12 13
Other See Terms and abbreviations on page 57. -
177.27 Transformer
overpressure action
Selects medium voltage transformer overpressure
action.
No action/
List
No action 0
Delayed warning 1
Warning and delayed
fault
2
Delayed fault 3
Fault and delayed MV
breaker opening
4
177.28 Transformer
overpressure delay
Defines delay time for medium voltage transformer
overpressure action.
0 s/ Real
0...3600 s 1 = 1 s
177.29 Transformer
overpressure current
limit
Defines current limit for medium voltage transformer
overpressure. The limit is active with all actions, except
for “no action”.
10000 A/
Real
0....10000 A 1 = 1 A
177.30 Transformer
overpressure failure
logic
Selects failure logic for medium voltage transformer
overpressure. The alarm is active high or active low.
Active High/
List
Active Low 0
Active High 1
177.31 MV vacuum failure
source
Selects source for medium voltage transformer vacuum
failure signal.
See also Digital inputs on page 50.
Off/ List
Off 0
No. Name/Value Description Def/
FbEq16/32
