Parameters 69
124.31 Lock-in level Defines lock-in level above which the Q(x) regulation
curve is activated.
20.0%/ Real
0.0 … 200.0% Lock-in level. 1 = 1%/
10 = 1%
124.32 Lock-out level Defines lock-out level. If the signal goes below the lock-
out level, the reactive power reference is reset to zero
until the lock-in level is exceeded.
5.0%/ Real
0.0 … 200.0% Lock-out level. 1 = 1%/
10 = 1%
124.33 Q(x) input level 1 Defines first input value for the Q(x) regulation curve.
When the selected input signal reaches this value, the
reactive power reference is set to the value defined with
parameter 124.39 Q(x) output level 1.
0.0%/ Real
- First input value for the Q(x) regulation curve. 1 = 1%/
10 = 1%
124.34 Q(x) input level 2 Defines second input value for the Q(x) regulation curve. 0.0%/ Real
- Second input value for the Q(x) regulation curve. 1 = 1%/
10 = 1%
124.35 Q(x) input level 3 Defines third input value for the Q(x) regulation curve. 0.0%/ Real
- Third input value for the Q(x) regulation curve. 1 = 1%/
10 = 1%
124.36 Q(x) input level 4 Defines fourth input value for the Q(x) regulation curve. 0.0%/ Real
- Fourth input value for the Q(x) regulation curve. 1 = 1%/
10 = 1%
124.37 Q(x) input level 5 Defines fifth input value for the Q(x) regulation curve. 0.0%/ Real
- Fifth input value for the Q(x) regulation curve. 1 = 1%/
10 = 1%
124.38 Q(x) input level 6 Defines sixth input value for the Q(x) regulation curve. 0.0%/ Real
- Sixth input value for the Q(x) regulation curve. 1 = 1%/
10 = 1%
124.39 Q(x) output level 1 Defines first reference output value for the Q(x)
regulation curve. When the selected input signal
reaches the value defined by parameter 124.33 Q(x)
input level 1, the reactive power reference is set to the
value defined by this parameter.
0.0% / Real
- First reference output value for the Q(x) regulation
curve.
1 = 1% /
100 = 1%
124.40 Q(x) output level 2 Defines second reference output value for the Q(x)
regulation curve.
0.0% / Real
- Second reference output value for the Q(x) regulation
curve.
1 = 1% /
100 = 1%
124.41 Q(x) output level 3 Defines third reference output value for the Q(x)
regulation curve.
0.0% / Real
- Third reference output value for the Q(x) regulation
curve.
1 = 1% /
100 = 1%
124.42 Q(x) output level 4 Defines fourth reference output value for the Q(x)
regulation curve.
0.0% / Real
- Fourth reference output value for the Q(x) regulation
curve.
1 = 1% /
100 = 1%
No. Name/Value Description Def/
FbEq16/32
