Parameters 71
125.04 Lv Gs trig U % Defines low voltage grid support trigger level. 90%/ Real
0 … 100% Low voltage grid support trigger level. 1 = 1%
125.05 Lv Gs K-factor Defines low voltage grid support gain for capacitive
reactive current.
1.00 /Real
0.00 … 10.00 Low voltage grid support gain for capacitive reactive
current.
100 = 1
125.06 Lv Gs P1 volt % Defines low voltage grid support voltage level 1. 90%/Real
0 … 100% Low voltage grid support voltage level 1 1 = 1%
125.07 Lv Gs P1 cur % Defines capacitive reactive current for low voltage grid
support voltage level 1.
25%/Real
0 … 100% Capacitive reactive current for low voltage grid support
voltage level 1.
1 = 1%
125.08 Lv Gs P2 volt % Defines low voltage grid support voltage level 2. 80%/Real
0 … 100% Low voltage grid support voltage level 2 1 = 1%
125.09 Lv Gs P2 cur % Defines capacitive reactive current for low voltage grid
support voltage level 2.
50%/ Real
0 … 100% Capacitive reactive current for low voltage grid support
voltage level 2
1 = 1%
125.10 Lv Gs P3 volt % Defines low voltage grid support voltage level 3. 60%/ Real
0 … 100% Low voltage grid support voltage level 3. 1 = 1%
125.11 Lv Gs P3 cur % Defines capacitive reactive current for low voltage grid
support voltage level 3.
80%/ Real
0 … 100% Capacitive reactive current for low voltage grid support
voltage level 3
1 = 1%
125.12 Lv Gs P4 volt % Defines low voltage grid support voltage level 4. 25%/ Real
0 … 100% Low voltage grid support voltage level 4 1 = 1%
125.13 Lv Gs P4 cur % Defines capacitive reactive current for low voltage grid
support voltage level 4.
100%/ Real
0 … 100% Capacitive reactive current for low voltage grid support
voltage level 4.
1 = 1%
125.14 Lv Gs P5 volt % Defines low voltage grid support voltage level 5. 0%/ Real
0 … 100% Low voltage grid support voltage level 5. 1 = 1%
125.15 Lv Gs P5 cur % Defines capacitive reactive current for low voltage grid
support voltage level 5.
100%/ Real
0 … 100% Capacitive reactive current for low voltage grid support
voltage level 5.
1 = 1%
125.16 Gs Hv symm sig Selects grid support voltage signal of symmetric swell. Same as Gs
LV/ List
Max LL rms voltage Maximum rms value of line-to-line voltage. 0
Min LL rms voltage Minimum rms value of line-to-line voltage. 1
Max phase rms voltage Maximum rms value of phase voltage. 2
Min phase rms voltage Minimum rms value of phase voltage. 3
Pos seq voltage Positive sequence component of voltage. 4
Same as Gs LV See 125.02 Gs Lv symm sig (page 70). 5
125.17 Gs Hv asymm sig Selects grid support voltage signal of asymmetric swell. Same as Gs
LV/ List
Max LL rms voltage Maximum rms value of line-to-line voltage. 0
No. Name/Value Description Def/
FbEq16/32
