72 Parameters
Min LL rms voltage Minimum rms value of line-to-line voltage. 1
Max phase rms voltage Maximum rms value of phase voltage. 2
Min phase rms voltage Minimum rms value of phase voltage. 3
Pos seq voltage Positive sequence component of voltage. 4
Same as Gs LV See 125.02 Gs Lv symm sig (page 70). 5
125.18 Hv Gs trig U % Defines high voltage grid support trigger level. 110 %/ Real
100 … 150% High voltage grid support trigger level. 1 = 1%
125.19 Hv Gs K-factor Sets high voltage grid support gain for inductive reactive
current.
1.00 / Real
0.00 … 10.00 High voltage grid support gain for inductive reactive
current.
100 = 1
125.20 Hv Gs P1 volt % Defines high voltage grid support voltage level 1. 110%/ Real
90 … 150% High voltage grid support voltage level 1. 1 = 1%
125.21 Hv Gs P1 cur % Defines inductive reactive current for high voltage grid
support voltage level 1.
-10%/ Real
-100 … 0% Inductive reactive current for high voltage grid support
voltage level 1.
1 = 1%
125.22 Hv Gs P2 volt % Defines high voltage grid support voltage level 2. 125%/ Real
90 … 150% High voltage grid support voltage level 2. 1 = 1%
125.23 Hv Gs P2 cur % Defines inductive reactive current for high voltage grid
support voltage level 2.
-30%/ Real
-100 … 0% Inductive reactive current for high voltage grid support
voltage level 2.
1 = 1%
125.24 Hv Gs P3 volt % Defines high voltage grid support voltage level 3. 150%/ Real
90 … 150% High voltage grid support voltage level 3. 1 = 1%
125.25 Hv Gs P3 cur % Defines inductive reactive current for high voltage grid
support voltage level 3.
-50%/ Real
-100 … 0% Inductive reactive current for high voltage grid support
voltage level 3.
1 = 1%
125.28 Frt Ireact ref ramp up Defines FRT reactive current ramp up time. 10 ms/ Real
0 … 1000 ms FRT reactive current ramp up time. 1 = 1 ms
125.29 Frt Ireact ref ramp down Defines FRT reactive current ramp down time. 10 ms/ Real
0 … 1000 ms FRT reactive current ramp down time. 1 = 1 ms
125.30 Frt Ipow ref ramp up Defines FRT active current ramp up time. 10 ms/ Real
0 … 1000 ms FRT active current ramp up time. 1 = 1 ms
125.31 Frt Ipow ref ramp down Defines FRT active current ramp down time. 10 ms/ Real
0 … 1000 ms FRT active current ramp down time. 1 = 1 ms
125.32 Frt Ireact ref % Shows FRT reactive current reference.
This parameter is read-only.
-/ Real
-200.0 … 200.0% FRT reactive current reference. 1 = 1%/
10 = 1%
125.33 Frt Ireact ref out % Shows ramped FRT reactive current reference.
This parameter is read-only.
-/ Real
-200.0 … 200.0% Ramped FRT reactive current reference. 1 = 1%/
10 = 1%
No. Name/Value Description Def/
FbEq16/32
