86 Parameters
135.103 AI overfrequency enable Enables anti-islanding overfrequency protection. 0 / Real
0...1 0 - Anti-islanding overfrequency protection disabled.
1 - Anti-islanding overfrequency protection enabled.
1 = 1
135.104 AI overfrequency limit Defines limit for anti-islanding overfrequency protection. 5.0 Hz/ Real
0.0...30.0 Hz Anti-islanding overfrequency protection limit. 1 = 1 Hz/
10 = 1 Hz
135.105 AI undervoltage enable Enables anti-islanding undervoltage protection. Instant
tripping without time delay occurs when anti-islanding
undervoltage limit is crossed.
0 / Real
0...1 0 - Anti-islanding undervoltage protection disabled.
1 - Anti-islanding undervoltage protection enabled.
1 = 1
135.106 AI undervoltage limit Defines limit for anti-islanding undervoltage protection. 7%/ Real
0...100% Anti-islanding undervoltage protection limit. 1 = 1%
135.107 AI overvoltage enable Enables anti-islanding overvoltage protection. Instant
tripping without time delay occurs when anti-islanding
overvoltage limit is crossed.
0 / Real
0...1 0 - Anti-islanding overvoltage protection disabled.
1 - Anti-islanding overvoltage protection enabled.
1 = 1
135.108 AI overvoltage limit Defines limit for anti-islanding overvoltage protection. 130%/ Real
100...200% Anti-islanding overvoltage protection. 1 = 1%
135.110 Rate of change of freq
enable
Enables rate of change of frequency protection. 0 / Real
0...1 0 - Rate of change of frequency protection disabled.
1 - Rate of change of frequency protection enabled.
1 = 1
135.111 Rate of change of freq
limit
Defines rate in which frequency is allowed to change. 1.0 / Real
0.0...10.0 Rate of frequency change. 1 = 1 /
10 = 1
135.131 Overfrequency enable 3 Enables overfrequency protection 3. 0/ Real
0...1 0 - Overfrequency protection 3 disabled.
1 - Overfrequency protection 3 enabled.
1 = 1
135.132 Overfrequency limit 3 Defines limit for overfrequency protection 3. 1.0 Hz/ Real
0.0...30.0 Hz Overfrequency protection 3 limit. 1 = 1 Hz/
10 = 1 Hz
135.133 Overfrequency time 3 Defines time for overfrequency protection 3. 100 ms/ Real
100...600000 ms Overfrequency protection 3 time. 1 = 1 ms
135.134 Overfrequency enable 4 Enables overfrequency protection 4. 0/ Real
0...1 0 - Overfrequency protection 4 disabled.
1 - Overfrequency protection 4 enabled.
1 = 1
135.135 Overfrequency limit 4 Defines limit for overfrequency protection 4. 1.0 Hz/ Real
0.0...30.0 Hz Overfrequency protection 4 limit. 1 = 1 Hz/
10 = 1 Hz
135.136 Overfrequency time 4 Defines time for overfrequency protection 4. 100 ms/ Real
100...600000 ms Overfrequency protection 4 time. 1 = 1 ms
135.137 Underfrequency enable
3
Enables underfrequency protection 3. 0/ Real
0...1 0 - Underfrequency protection 3 disabled.
1 - Underfrequency protection 3 enabled.
1 = 1
No. Name/Value Description Def/
FbEq16/32
