ABB PVS980-58 User Manual

Parameters 85
135.72 Overvoltage enable 4 Enables overvoltage protection 4. 0 / Real
0...1 0 - Overvoltage protection 4 disabled.
1 - Overvoltage protection 4 enabled.
1 = 1
135.73 Overvoltage limit 4 Defines limit for overvoltage protection 4. 130 %/ Real
100...200 % Overvoltage protection 4 limit. 1 = 1 %
135.74 Overvoltage time 4 Defines trip time for overvoltage protection 4. 100 ms/ Real
100...600000 ms Overvoltage protection 4 trip time. 1 = 1 ms
135.75 Sliding overvoltage
enable
Enables sliding overvoltage protection. 0 / Real
0...1 0 - Sliding overvoltage protection disabled.
1 - Sliding overvoltage protection enabled.
1 = 1
135.76 Sliding overvoltage limit Defines limit for sliding overvoltage protection. 120 %/ Real
100...200 % Sliding overvoltage protection limit. 1 = 1 %
135.77 Sliding overvoltage time Defines trip time for sliding overvoltage protection. 100 ms/ Real
100...600000 ms Sliding overvoltage protection trip time. 1 = 1 ms
135.80 Combinatory trip Enables combinatory protection. 0 / Real
0...1 0 - Combinatory protection disabled.
1 - Combinatory protection enabled.
1 = 1
135.81 Combinatory trip time Sets trip time for combinatory protection. 100 ms/ Real
100...600000 ms Combinatory protection trip time. 1 = 1 ms
135.84 Comb pos seq voltage
limit
Defines positive sequence voltage limit in percentage of
nominal line-to-line AC voltage for combinatory
protection.
130%/ Real
0...200% Combinatory protection limit for positive sequence
voltage.
1 = 1%
135.85 Comb neg seq voltage
limit
Defines negative sequence voltage limit in percentage
of nominal line-to-line AC voltage for combinatory
protection.
10%/ Real
0...200% Combinatory protection limit for negative sequence
voltage.
1 = 1%
135.86 Comb underfrequency
limit
Defines limit for combinatory underfrequency protection. -5.0 Hz/ Real
-30.0...0.0 Hz Combinatory underfrequency protection limit. 1 = 1 Hz/
10 = 1 Hz
135.87 Comb overfrequency
limit
Defines limit for combinatory overfrequency protection. 5.0 Hz/ Real
0.0...30.0 Hz Combinatory overfrequency protection limit. 1 = 1 Hz/
10 = 1 Hz
135.100 Anti-islanding Enables anti-islanding (AI) function. 0 / Real
0...1 0 - Anti-islanding function disabled.
1 - Anti-islanding function enabled.
1 = 1
135.101 AI underfrequency
enable
Enables anti-islanding underfrequency protection. 0 / Real
0...1 0 - Anti-islanding underfrequency protection disabled.
1 - Anti-islanding underfrequency protection enabled.
1 = 1
135.102 AI underfrequency limit Defines limit for anti-islanding underfrequency
protection.
-5.0 Hz/ Real
-30.0...0.0 Hz Anti-islanding underfrequency protection limit. 1 = 1 Hz/
10 = 1 Hz
No. Name/Value Description Def/
FbEq16/32
