PID-3875-OUTPUTSIGNALS v9
Table 45: ZCVPSOF Output signals
Name Type Description
TRIP BOOLEAN Trip output
6.3.5 Settings
IP15016-1 v2
PID-3875-SETTINGS v10
Table 46: ZCVPSOF Group settings (basic)
Name Values (Range) Unit Step Default Description
Operation Off
On
- - Off Operation Off / On
AutoInitMode DLD disabled
Voltage
Current
Current & Voltage
-
- DLD disabled Automatic switch onto fault initialization
Mode Impedance
UILevel
UILvl&Imp
-
- UILevel Mode of operation of SOTF Function
IPh< 1 - 100 %IB 1 20 Current level for detection of dead line in
% of IBase
UPh< 1 - 100 %UB 1 70 Voltage level for detection of dead line in
% of UBase
tDuration 0.000 - 60.000 s 0.001 0.020 Time delay for UI detection (s)
tSOTF 0.000 - 60.000 s 0.001 1.000 Drop off delay time of switch onto fault
function
tDLD 0.000 - 60.000 s 0.001 0.200 Delay time for activation of dead line
detection
tOperate 0.03 - 120.00 s 0.01 0.03 Time delay to operate of switch onto
fault function
Table 47: ZCVPSOF Non group settings (basic)
Name
Values (Range) Unit Step Default Description
GlobalBaseSel 1 - 12 - 1 1 Selection of one of the Global Base
Value groups
6.3.6 Monitored data
PID-3875-MONITOREDDATA v7
Table 48: ZCVPSOF Monitored data
Name
Type Values (Range) Unit Description
IL1 REAL - A Current in phase L1
IL2 REAL - A Current in phase L2
IL3 REAL - A Current in phase L3
Table continues on next page
Section 6 1MRK 506 382-UEN A
Impedance protection
132 Line distance protection REL650 2.2 IEC
Technical manual
